Details
From sprints to Olympic and Ironman distance triathlons, here’s your aero advantage. Trinity Advanced is integrated with everything you need to score a new PR.
Built with Advanced-grade composite materials and engineered with AeroSystem Shaping Technology, this frameset improves aerodynamics in real-world triathlon conditions. Its AeroSystem Shaping means that every tube shape is designed to minimize drag no matter which direction the wind is blowing. The Contact base bar offers maximum adjustability, so you can dial in your perfect position for comfort and performance. And the SpeedControl brakes offer confident control without sacrificing aerodynamics.
Aero efficiency
Extensive CFD analysis, dynamic wind tunnel testing, and triathlon-specific design result in superior aero performance in a race-ready configuration.
Integrated design
Everything from the frame shape to the aero seatpost and brakes are engineered to perform as a system.
Perfect fit
Refined frame geometry and a wider range of adjustability allow for a triathlon-specific fit that’s designed to meet the unique demands of multisport racing.
Specs
Frame | Advanced-Grade Composite |
---|---|
Fork | Advanced-Grade Composite, alloy OverDrive steerer |
Rims/Wheels | Giant SR-2 wheelset |
Hubs | Giant SR-2 wheelset |
Spokes | Giant SR-2 wheelset |
Tires | Giant Gavia Course AC 1, tubeless, 700x25, folding |
Crankset | Shimano FC-RS510 |
Chainrings | 50/34T |
Bottom Bracket | Shimano, press fit |
Chain | KMC X11EL-1 |
Front Derailleur | Shimano 105 |
Rear Derailleur | Shimano 105 |
Cassette/Rear Cogs | Shimano 105, 11x28 |
Shifters | Shimano TT SL-BSR 1 |
Handlebars | Giant alloy Contact base bar aluminum extension ski bend |
Stem | Giant Connect |
Brake Levers | Tektro RX 4.1 |
Brakes | Front: TKB84 rear: TBK88 |
Saddle | ISM PS1.0, steel rail |
Seat Post | Trinity composite |
Accessories & Extras | Integrated food storage |
* Subject to change without notice.
Part Numbers
Option | UPC | MPN | Store SKU |
---|---|---|---|
Charcoal/Pure Red / Medium | 04712878473560 | 2000015104 | 5629 |
